Repository blueprint suggestions ​

The Suggested tab appears in Create project from GitHub after a repository is selected or pasted. It analyzes the repository and recommends one catalog blueprint so users can start with a sensible team, workflow, review policy, and sandbox posture without writing a generation prompt.

For the API contract see the reference; for the implementation flow see the deep dive.

When it appears ​

Open Projects → Create from GitHub. The dialog has repository fields on the left and the shared Blueprint panel on the right. The right side defaults to Suggested and offers three tabs: Suggested, Templates, and Generate (apps/web/src/pages/ProjectGalleryPage.tsx:676).

The Suggested panel only analyzes when both are true:

  • the tab is active; and
  • the repository field has an owner/repo value (apps/web/src/components/BlueprintPicker.tsx:301).

If no repository is selected, the card says Select a repository first and explains that Agentweaver will analyze it and suggest a matching blueprint (BlueprintPicker.tsx:318).

Step by step ​

  1. Click Create from GitHub.
  2. Choose a repository from search/recent/account results, or paste an owner/repo value. The account list starts with the signed-in user's personal account, shown as @{login} with a You badge, then lists organizations; selecting any account reloads its repositories (apps/web/src/pages/ProjectGalleryPage.tsx:471, :501, :642, :645). Selecting a repo autofills the project name and folder slug when those fields have not been edited (ProjectGalleryPage.tsx:559).
  3. Stay on Suggested. The panel shows Analyzing repository... while apiClient.suggestBlueprint calls POST /api/blueprints/suggest (BlueprintPicker.tsx:305).
  4. Review the Recommended card. It shows the blueprint name, rationale, roster chips, agent count, and confidence percentage (BlueprintPicker.tsx:337).
  5. Expand details to see repository signals such as description, topics, languages, root files, and issues-enabled (BlueprintPicker.tsx:350).
  6. Click Use this blueprint to apply it. If the recommendation is not right, click View all templates → to switch to Templates, or choose Generate for a custom blueprint (BlueprintPicker.tsx:350, :352, :371).

Create from GitHub dialog showing the Suggested blueprint recommendation

📸 Screenshot — repo-blueprint-suggestions.pngShows: Create project from GitHub with a selected or pasted repository, the Suggested blueprint tab, the Recommended card, rationale, roster chips, confidence percentage, and repository signals. Path: Sign in → /projects → Create from GitHub → choose or paste a repository → stay on Suggested.

  1. Click Create project. The create request carries the chosen catalog blueprint id or generated inline blueprint through the existing project creation path (BlueprintPicker.tsx:371).

How the recommendation is chosen ​

The recommendation is a catalog match, not a model-generated blueprint. The API reads GitHub metadata, languages, and root files using the submitting user's GitHub token, builds display signals, then maps AI/LLM repos, docs/content repos, product/design repos, and code repos to catalog blueprint ids (apps/Agentweaver.Api/Blueprints/GitHubRepoBlueprintSuggestionService.cs:51, :132, :149).

That means the recommendation is fast and predictable. If you want a bespoke team or workflow from a written description, switch to Generate and click Generate blueprint (apps/web/src/components/BlueprintPicker.tsx:236).

Fallback to Templates ​

If repository analysis cannot run, the experience does not block project creation. The panel shows a warning such as Repository analysis unavailable. Choose a template instead. and offers View all templates →, which switches to the shared Templates tab (BlueprintPicker.tsx:323, :371). The same fallback appears for invalid repository strings, unavailable GitHub metadata, network failures, and service fallback responses (GitHubRepoBlueprintSuggestionService.cs:89, :93).

Personal repositories ​

The GitHub picker now includes personal repositories, not only organization repositories. GET /api/github/accounts returns the authenticated user first with type: "user", and the UI labels that entry You (apps/Agentweaver.Api/Endpoints/AuthEndpoints.cs:207, :249; apps/web/src/pages/ProjectGalleryPage.tsx:642). GET /api/github/repos?account=<login> uses GitHub /user/repos?affiliation=owner when the account is the signed-in user, so search, recent repositories, and manual selection all surface personal repositories too (AuthEndpoints.cs:295, :333; apps/web/src/api/client.ts:267).
